On Friday, August 13, the German Windpower Museum managed to win another truly unique exhibit:
The blade of an Enercon E-20, fully made of aluminium, was prepared and loaded at the Enercon factory in Aurich and sent to the museum in Stemwede.
The 10m blade is silver/light-greyish coloured and features all the Enercon typical specialties like the Albert Betz ideal blade geometry for higher output or the folded blade tips for noise reduction.
The blade was atually designed for the small-scale machine Enercon-20 – a 100kW turbine placed on a tube tower for application on farms, remote areas or developing countries. The machine came out as a prototype in 2007, but never went into serial production. Less than five were poduced.
Another fact is the Enercon E-20 was fully stall-controlled in contrast to the whole Enercon portfolio of the 2000s – with exception of the even smaller E-10.
The aforementioned aerodynamical features are major milestones in the technological development of Enercon and were applied thousands of timed across the world.
The “tiny” 10m aluminium blade demonstrates all these milestones “on eye-level” and hands-on.
Taking into account the progressive technology and the fact that Enercon-founder, Mr. Aloys Wobben, has recently died making an era end, the seemingly meaningless blade turns out to be of high importance.
The project was initiated by museum manager Jaeger. The transport was taken over by Wilfried Nobbe.
The German Windpower Museum cordially thanks Enercon for making this donation!
The collection of the German Windpower Museum has gotten richer by an exiting exhibit: This time it’s not about a real wind turbine or parts of it – but a big model.
To be exact it’s a Heidelberg-Motor HM-300. Contrary to almost all wind turbines this is a vertical axis wind turbine with two blades standing upright. The appearance of the rotor mirrors the letter “H” telling why these machines are usually called “H-Rotors”.
One hoped to achive major advantages to conventional horizontal axis wind turbines e.g. fewer components, less wear, a simpler design and easier maintenance.
The Heidelberg-Motors got their ring generator placed either on top or at the bottom of the tower.
The model is made of balsa wood and hard paper and shows the three-leg tower version with the ring generator placed on top.
Of this extremely rare version five units were installed at Kaiser-Wilhelm-Koog (Schleswig-Holstein) in 1995 – being unique worldwide until today.
Due to technical and economial reasons the H-Rotors never really enjoyed a breakthrough on the wind turbine market. The windfarm at Kaiser-Wilhelm-Koog had to be dismantled after two years for technical reason.
However, a very rare, short yet highly interesting chapter of German wind power history is now on display in Stemwede.
The donation of the model was made by a former company employee. Organization and transport was done by manager Jaeger.
After a longer break the German Windpower Museum has reached a new milestone on Friday 7, May 2021. With the TW 300 the first open space exhibit of the former significant German pioneer Tacke has arrived at the museum.
The TW 300 was a 300kW-machine with a 33m rotor and a 40/50m tubular tower. There was a total of 15 units of this machine in Germany. A further 15 units were sold abroad. The TW 300 was sold between 1994 and 2000.
Nacelle, the three blades and the hub are from Athenstedt in Saxony. The turbine was installed in 1995.
Society member Heinrich Bartelt and museum manager Jaeger were responsible for realizing this outstanding project.
Special thanks to AK Fehmarn GmbH & Co. KG for organizing the single turbine components on site as well as taking over the costs for transportation to Stemwede.
In addition the German Windpower Museum welcomes AK Fehmarn as new sponsor!
This project was made possible solely through all this engagement.
The current issue 01/2021 of Windkraft Journal features a two-pages article about the Hartkemeyer homemade turbine and its receipt by the German Windpower Museum. In addition, the two US-machines from Kenetech and Bergey are presented. The article was written by manager Jaeger.
Article in German only.
Click for reading:
With the arrival of an American Bergey BWC Excel the German Windpower Museum registers its second US machine.
The machine from Oklahoma is rated at 10kW at a diameter of 7m. It was imported from the US by Dutch wind turbine manufacturer LMW and installed in Belm by German manufacturer NEW in 1991.
After the turbine was removed from its site in the 2000s it was supposed to be reinstalled in Hunteburg near Bohmte (Lower Saxony). But it never happened.
Bergey is a US pioneer in the field of wind energy and active since 1977. Until today the small company produces wind turbines up to 50kW. Its machines are ubiquitious in North America. Worldwide Bergey machines can often be found in remote areas.
Last week the German Windpower Museum registered a very exotic new entrant for an longer time since.
The first US wind turbine from earlier wind pioneer Kenetech is now on the premises of the museum.
This is the nacelle of a Kenetech 33M-VS with a rated power of 365kW and a diameter of 33m. It was originally placed in Eemshaven, the Netherlands and was one out of 94 units that made up one of Europe’s largest wind farms in 1995!
However, these machines disappeared in 2008.
Until 1993 Kenetech was called U.S. Windpower and was one of the first US companies who developed and mass produced wind turbines since the late 1970s. All in all U.S. Windpower produced more than 4000 units of which the majority was installed in the USA. U.S.W.P. made huge profits during the 1980s wind boom in California and grew to the biggest and strongest US manufacturer then.
During the 1990s the company intended to gain ground on the European market with its new 33M-VS but realized “just” two large wind farms (Netherlands, Spain) before filing for bankruptcy in 1996 and vanishing. There were plans for wind farms in Germany as well.
The German Windpower Museum receives this nacelle as a permanent loan from the German Museum of Technology of Berlin to which it holds a long time contact.
The permanent loan was made possible due to the long time engagement of Dr. Jochen Hennig of the German Museum of Technology and Mr. Jaeger manager of the German Windpower Museum. Further common projects are in the pipe.
With the receipt of this nacelle the German Windpower Museum reaches a new milestone. On the one hand the USA as a wind power pioneering country are now represented. On the other hand it is the first machine from a different continent – abroad from Europe!
Thus, the international orientation of the museum gets a further incentive.
The German Windpower Museum cordially thanks the German Museum of technology for this permanent loan and the support that comes with it!
Considering the huge “removal wave” Germany is approaching the German Windpower Museum is keen on taking over more used wind turbines.
Consequently an appeal was started in the magazine Windkraft Journal.
Furthermore, the article deals with the arrival of a metal blade made by Allgeier in the 1950s/60s.
As done before we like to thank Windkraft Journal for theier support!
Click to read. Article in German only.
Diepholzer Kreisblatt and Westfalen Blatt (regional newspapers) have reported about the visit of seven pupils who are part of a nature-history working group from Birger-Forell-School of Espelkamp.
Article in German only.
Westfalen Blatt has reported about a cooperation between the German Windpower Museum (DWM) and Deutsche Gesellschaft für Mühlenkunde & Erhaltung (DGM) planned for the near future.
The following article tells all details. Article in German only.
With the arrival of the Enercon-18, 80kW, the German Windpower Museum is one legendary exhibit richer. Thanks to the engagement of Enercon and museum manager Jaeger a complete blade set and a nacelle were saved from scrapping.
This unit was originally installed on a concrete tower at Hohne close to Celle in Lower Saxony. Units equipped with a steel three-legged tower were applied as well.
This turbine type was popular among farms in northern Germany. It was often applied at sewage plants, too.
Between 1991 and 1995 more than 100 units of Enercon-18 were manufactured. Thus, it is considered a best seller within its power range.
Enercon-18 either had an 18m or 19,4m rotor. The high-quality blades were manufactured by danish LM.
Still for this turbine type a transmission was used and the drivetrain was fully integrated meaning that all components were assembled as one compact unit.
The German Windpower Museum thanks Enercon for this technologically attractive donation!
A very rare exhibit has made its way from Lubing, Barnstorf to the German Windpower Museum. A tiny windpump from the 1960s was intensively overhauled by a Lubing employee and can now be spotted in the museum as a permanent loan. Erwin Scissek, a society member, was the initiator of this project.
Still today, Lubing wind pumps appear on meadows, farms or along dikes. In most cases it’s downwind turbines equipped with blue colored plastic blades and four or six bladed rotors. They are used for water pumping or ventilation. Especially in northern Germany these wind pumps were ubiquitous.
Thanks to Lubing for this outstanding engagement!
The German Windpower Museum is – once again – one more exhibit richer. This time it’s a very special machine which heavily influenced the German and international wind scene in the 1990s. The Enercon E-40, made by Enercon, rated at 500kW and equipped with a 500kW ring generator was the sensation at its market introduction in 1993. There was no comparable wind turbine of its class before that dismissed a transmission.
The E-40 was more than a milestone even for Enercon. It meant more than just a technological skip from conventional wind turbines with transmissions to gearless machines. It was the first international and commercially successful breakthrough for the Aurich based company.
The unit in Stemwede originates from 1995 and, thus, is an E-40 5.40 with 65m hub height, tubular steel tower and 40m diameter. The turbine stood in close proximity to the former test site of DEWI, located in Wilhelmshaven-Sengwarden.
Of this “original” E-40 alone more than 1000 units were manufactured until 1999. Thus, it is considered the most successful wind turbine in 1990s Germany – surpassing the Tacke TW600. In addition, this wind turbine proved that ring generators are suitable for mass production and can stand technical criteria. Thus, conventional wind turbines with transmission faced “new competition”.
In the late 1990s follow-up models with larger diameters, increased rated power (E-40 6.44) and the well-known “egg shape” were introduced.
This transfer was enabled by the engagement of manager Jaeger and company Enercon who we would like to thank for this outstanding cooperation with the German Windpower Museum!
On November 14, three members of the German Windpower Museum met representatives of GEW (utility) in the futuristic building of the former jade wind farm close to Wilhelmshaven.
It was all about the intention to take down the closed facility and reinstall it at Stemwede as part of the German Windpower Museum.
The building was installed in the late 1980s as part of Jade wind farm, then new and spectacular. Three single-blade turbine of type Monopteros-50 made by MBB, made up the core of the former wind farm. With a rated power of 640kW and 56m diameter they were the largest single-bladers the wind industry had ever seen.
In 1993 the Jade wind farm was extended by a 3MW two-blader. Aeolus II by Kvaerner/MBB was the fourth highly visible large-scale turbine, served as a prototype and led to even more exclusivity for the Jade wind farm..
In the previously mentioned building visitors were able to get a detailed impression and retrieve live data of all four machines. In addition to that people were informed about wind energy in general.
All wind turbines of the Jade wind farm disappeared between 2001 and 2008. Thus, keeping the existing building is of high importance.
Both sides gave a positive signal at this first meeting. GEW as well as German Windpower Museum think there’s a chance in transferring and keeping this building. Further steps are planned.
The German Windpower Museum thanks representatives of GEW for this first meeting.
The regional newspapers Westfalen Blatt and Diepholzer Kreisblatt have reported about the current developments in the German Windpower Museum. The content is mainly about the future cooperation between the club and a Berlin PR agency concerning further professionalization and increase of the degree of fame.
The German Windpower Museum thanks for the reports.
Articles in German only.
The August issue of Windpower Monthly features a four-page report describing the activities of the German Windpower Museum in detail in the English language.
One of the club’s exhibits (Trebur) made its way on the cover (left half).
It is the first international report about the society and will be read by an international reading public.
Windpower Monthyl is published since 1985 and is considered to be the leading international wind energy magazine for many years.
The German Windpower Museum cordially thanks all involved for this milestone of communicating the society!
The entire article can be downloaded as PDF file:
The current issue of “Neue Energie” features the German Windpower Association (BWE) supporting the German Windpower Museum in the future.
The club thanks to “Neue Energy” for this article and to BWE for its engagement.
Article in German only.
Dear club members!
Dear wind energy friends!
The society name „Mühlheide Windpower Museum“ is deregistered with direct effect.
All future activities concerning the windpower museum located at Mühlheide will be subject to the name
“German Windpower Museum”.
The renaming was decided within a general club meeting and is related to the national and international approach of the museum.
Site and general targets will stay the same.
For the sake of completeness older articles from the Mühlheide Windpower Museum will remain for people interested.
Right out of the headquarter of Enercon, Aurich, the drivetrain of an Enercon-17, rated at 80kW, has been delivered to Mühlenheide Windpower Museum.
The E-17 is one of Enercon’s first wind turbines of considerable success, since more than 100 units (various versions) of this series (E-17/E-18) were made. Since its market introduction in 1987 this 80kW machine was manufactured until the mid 1990s.
From a pedagogic view this drivetrain proves valuable due to the missing nacelle cover and the possibility to touch it at eye-level. All main components of a modern wind turbine can be spotted directly without a cover standing in the way.
This project required quite some organization carried out by manager Jaeger. Transporting the 5 Tons object was taken over by Mr. Nobbe from Twiehausen, who loves to support the museum.
Mühlenheide Windpower Museum cordially thanks Enercon for this donation!
We would like to give special thanks to the employees for their friendly support and a smooth process!
On the premises of the museum members of Mühlheide Windpower Museum have built an amusement house for the Oppendorf kindergarden. The installation at its final place on the premises of the kindergarden will be carried out by members of the museum on calendar week 28 and 29. Due to the massive weight of the object willingly supporters will be needed. The project was financed by local wind farm operators.
Two days ago the Mühlheide Windpower Museum became one more wind turbine richer. This time one of the first Kukate wind turbines from the early 1980s came in.
These are solid, purely mechanically running turbines in the range up to 10kW which can easily be produced by small enterprises or single persons on their own. The Kukate concept is also applicable for developing countries.
This process was made possible by manager Jaeger who personally managed the transport. The owner, Mr. Droste from Diepenau, is an active member of Mühlheide Windpower Museum and quickly agreed on the transportation of the turbine – after it got wrecked by a storm.
